Car GPS Navigation Android 7" Capacitive touch screen Navigator Bluetooth Quad-c

  • Car GPS Navigation Android 7" Capacitive touch screen Navigator Bluetooth Quad-c
  • Car GPS Navigation Android 7" Capacitive touch screen Navigator Bluetooth Quad-c
  • Car GPS Navigation Android 7" Capacitive touch screen Navigator Bluetooth Quad-c
  • Car GPS Navigation Android 7" Capacitive touch screen Navigator Bluetooth Quad-c
  • Car GPS Navigation Android 7" Capacitive touch screen Navigator Bluetooth Quad-c
  • Car GPS Navigation Android 7" Capacitive touch screen Navigator Bluetooth Quad-c
Model No.︰H799
Brand Name︰-
Country of Origin︰China
Unit Price︰-
Minimum Order︰-
Share on:

 Total 2 Related Items
Prev12

Product Description

Item specifics

  • Brand Name:henhaoro
  • GPS type:Vehicle GPS Units & Equipment
  • Special Features:FM Transmitter,Touch Screen,MP3/MP4 Players,Bluetooth
  • Screen Resolution:800x480

Product Description

GPS-A1GPS-A2GPS-A3GPS-A4GPS-A5GPS-1GPS-2GPS-3GPS-4GPS-5GPS-6GPS-7



Specification
CPU ARM MTK8127 Cortex A7*4 1.3GHz
GPU 2D/3D        Open GL ES 2.0
VPU

Video encoding
and decoding

MPEG1/2/4 H.264 H.263 VC-1 AVS VP8 1080P H.264 1080P
(Decoding 4x HD format: MPEG1/2/4, H.264, H.263, VC-1 , AVS, VP8 to, decoding 1080P HDdecoding to support the whole format.
Encoding support 1080P encoding of the H.264 format.)
Display Size 7 inch
Resolution 800 * 480 pixels
Color 262114-color
Backlight LED
Memory & Flash Memory Lpowerddr2 512MB/
Solid-state disk MLC Nand Flash /8GB 64bit ECC SLC/MLC/TLC 15MB/s
(MLC Nand Flash /8GB, built-in MLC controllers can support up to 64bit of ECC SLC / MLC / TLC 15MB/s

Power and Battery
Adapter AC 100 240V DC 5V / 2A MINI USB socket (not including)
Car Charge       DC +12V DC +5V, 2A, MINI USB socket
Battery Type Lithium Battery (Rechargeable)
Working current 580-800mA/3.7V(Backlight Brightest)
330-370mA/3.7V(Backlight Darkest)
550-800mA/3.7V(play mp3)
Maximum Working current <1.45A
Suspendcurrent <5mA
Charging current Max:1050mA
Battery capacity  3.7V/850-3000mAh
Battery life (7")(Approximately 5-6 hours)
GPS/wifi/BT/FM Built-in GPS Receiver   Ordering Information MT6627
PositionAccuracy Without Aid: 10 m 2D-RMS
 Velocity Accuracy Without Aid: 0.1 m/s
Acceleration Accuracy Without Aid: 0.1 m/s2
Timing Accuracy < 100 ns
   Sensitivity Tracking:-159 dBm Hot Start:-159 dBm
Warm Start: -159dBm Cold Start: :-159dBm
Autonomous Acquisition: -145dBm
TTFF (Time To First Fix) Cold Start: < 45 s (Autonomous)
Warm Start: < 35 s
Hot Start: < 2 s
Reacquisition Time < 1 s
Maximum Altitude 18,000 m
Maximum Acceleration 4 G
Maximum Velocity 515 m/s
Wi-Fi * Operates in 2.4 GHz frequency bands,B/ G /N
* 1x1 MIMO technology
improves effective throughput and range existing 802.11 b/g products
* Data rates: up to 150Mbps
* 802.11e-compatible bursting and I standards
* BPSK, QPSK, 16 QAM, 64 QAM modulation schemes
* WEP, TKIP, and AES, WPA, WPA2 hardware encryption schemes
BT YES : The technology in application of bluetooth to transfer data (music, video) to the device
FM YES only for transmitter
FM built in FM transmitter     KT0806
76MHz~108MHz
Gravity sensor without
Speaker  1* 1W / 8Ω
Peripheral Interface SD card slot Support SD1.0 to SD3.0 , MMC3.3 to 4.3
USB  USB 2.0 Host x 1 / OTG x 1
USB USB2.0, high speed,
USB host External U disk connection,MP3,MP4,storage device
such as mobile hard disk can play
directly Supports external 3G USB-dongle wireless internet card

Built-inAVIN yes 2.5mm port for  (For rear veiw camera)

Input device Multi-points capacitive screen
Support for mouse and keyboard input via the USB interface
Multimedia Video Player Supports Super high definition 2160P,Supports MKV,AVI,WMV,RMVB,TS,TP,M2TS,RM,MPEG,VOB,MOV,FLV,MP4,3GP,DAT,PMP format for video play.
Ebook Reader TXT,LRC,PDF,HTML,HTM,EPUG,PDF,FB2
Audio Player WMA, MP3,OGG,APE,FLAC,AAC,WAV
Photo Viewer JPG, BMP,PNG,GIF
what in the box    Car adapter,USB Cable,user manual, mounting bracket,
Travel charger(optional),SD Card(optional).
LED Indicator Charging:Red on ,Battery Full:Red off and Green on
Temperature Operation: -10~60°C
Dimensions about:195mm×110mm*10mm



7" GPS Car Navigation Android 4.4 Quad-Core 8G Bluetooth WIFI FM Truck Vehicle Navigators with maps













Detailed Maps with Free Updates



Detailed maps With free lifetime map updates, your routes are sure to reflect the most up-to-date maps, POIs (points of interest) and navigation information.



Support Europe / North America / South America / Southeast Asia / Middle East map (We will install map according to your address, such as: Russia, we will install the map of Russia)



More Information at a Glance



The device keeps your driving map onscreen at all times and additional information appears alongside. For details, simply ask or touch the screen. As you drive your route, Up Ahead constantly informs you of nearby services, including restaurants, fuel stations, hospitals and stores .





3D scene for the complex intersection



Easy-to-understand driving directions that guide like a friend, using recognizable landmarks, buildings and traffic lights



Notice:

1, The device is 8GB, but about 3.44GB for the system installed.

2, Please connect the car charger after start the car when you use it;

3, The device only can be used outside the door, because the building will cut all GPS signal.

4, Why the RAM testing result is not enough to 512MB. Because the system of the device  take  up some capacity. All tablet pc, Phone, GPS has this problem.



  • The Good Material of the GPS and The Workmanship, The Good Maps; Faster GPS Signal Info .

  • Android 4.4.2 , MT8127 CPU,ARM Cortex-A7 quad-core processor, 1.3GHz; Built in 8GB, 512MB RAMx8bits DDR
  • 7 inch Capacitive screen 800*480 TFT large screen, play games, watch videos, clear to see the road and Multi-touch capacitive touch screen, clear, sensitive and can respond to slight touch.

  • Built-in WiFi support 802.11 b/g/n, you can surf in the internet, watch videos , chat with IM, download what you want and update the software on line.

  • Bluetooth : The technology in application of bluetooth to transfer data (music, video) to the device

  • FM emission function, the navigation voice and music will be directly sent to the car speaker. With this function, the sound become better and louder

  • 3D navigation, no need to worry about the complex viaduct and the maze crossing.

  • Smart voice journey reminding all the way, no need to worry about driving past the road.

  • We will preload maps according to the country name in the shipping address.If you want extra maps,please leave us a note .

  • Maps offers free upgrades for life, when there is a new map, we will send to your email .

  • Support Offline GPS Navigation





Packaging Details

  • Unit Type: piece
  • Package Weight: 0.35kg (0.77lb.)
  • Package Size: 1cm x 1cm x 1cm (0.39in x 0.39in x 0.39in)
